Mechanical Installation
6.2.4 Terminal Locations - Frame Size E
Terminal Locations - Frame Size E1
Take the following position of the terminals into consideration when designing the cable access.
Dimensions are shown in mm [in].
NOTICE
Power cables are heavy and hard to bend. Consider the optimum position of the frequency converter to ensure easy
installation of the cables. Each terminal allows the use of up to 4 cables with cable lugs or the use of a standard box
lug. Earth is connected to a relevant termination point in the frequency converter.
6
6
Illustration 6.60 Terminal in Detail
132
®
VLT
AutomationDrive FC 300 Design Guide 90-1200 kW
104[4.1]
35[1.4]
10[0.4]
0[0.0]
MG34S202 - Rev. 2013-08-19
