Mechanical Installation
1447
[57.0]
6 6
Illustration 6.17 Mechanical Dimensions, D6h
1 Ceiling
2 Air space outlet minimum 225 mm [8.9 in]
3 Air space intlet minimum 225 mm [8.9 in]
4 Floor
Table 6.11 Legend to Illustration 6.17
NOTICE
If using a kit to direct the airflow from the heat sink to
the outside vent on the back of the frequency converter,
the required ceiling clearance is 100 mm.
104
®
VLT
381
[15.0]
115
[4.5]
23
[0.9]
159
[6.3]
181
1617
[7.1]
[63.7]
909
[35.8]
AutomationDrive FC 300 Design Guide 90-1200 kW
306
[12.1]
180
[7.1]
123
[4.8]
78
[3.1]
200
[7.9]
1663
1615
[65.5]
[63.6]
123
[4.8]
78
[3.1]
200
[7.9]
200
[7.9]
1
25
[1.0]
Illustration 6.18 Detail Dimensions, D6h
1 Top mounting hole detail
2 Bottom mounting slot detail
Table 6.12 Legend to Illustration 6.18
MG34S202 - Rev. 2013-08-19
325
[12.8]
276
130
[10.9] 1
[5.1]
130
[5.1]
1452
[57.2]
559
4
[22.0]
11
63
[0.4]
[2.5]
15
9
20
[0.6]
[0.3]
[0.8]
4X 11
[0.4]
2
3
2
63.5
[3]
24
[0.9]
