Electrical Installation
Input Polarity of Control Terminals
12 13 18
7 7
Illustration 7.45 Input Polarity of Control Terminals (PNP
Source)
12 13 18
Illustration 7.46 Input Polarity of Control Terminals (NPN Sink)
NOTICE
Use screened/armoured cables to comply with EMC
emission specifications. For more information, see
7.8 EMC-Correct Installation.
206
VLT
PNP (Source)
Digital input wiring
19 27 29 32 33
NPN (Sink)
Digital input wiring
19 27 29 32 33
®
AutomationDrive FC 300 Design Guide 90-1200 kW
20 37
Illustration 7.47 Shield Termination and Strain Relief of
Control Cable
20 37
