Mechanical Installation
2281
(89.8)
2206
(86.9)
1499
(59.0)
Illustration 6.25 Mechanical Dimensions, F2
1
Minimum clearance from ceiling
Table 6.17 Legend to Illustration 6.25
®
VLT
AutomationDrive FC 300 Design Guide 90-1200 kW
1804
(71.0)
MG34S202 - Rev. 2013-08-19
1
225.0
Ø29
(8.85)
(1.1)
606
(23.8)
6
6
