Selection
FC 302
High/Normal load*
Typical shaft output at 400 V [kW]
Typical shaft output at 460 V [HP]
Typical shaft output at 500 V [kW]
Enclosure IP21
Enclosure IP54
Output current
Continuous (at 400 V) [A]
Intermittent (60 s overload)
(at 400 V) [A]
Continuous (at 460/500 V) [A]
Intermittent (60 s overload)
(at 460/500 V) [A]
Continuous KVA (at 400 V) [KVA]
Continuous KVA (at 460 V) [KVA]
Continuous KVA (at 500 V) [KVA]
Maximum input current
Continuous (at 400 V) [A]
Continuous (at 460/500 V) [A]
2
Max. cable size, mains [mm (AWG)
2
Max. cable size, motor [mm (AWG)
Max. cable size, brake [mm 2 (AWG)
2)
Max. external mains fuses [A]
Estimated power loss
3) 4)
at 400 V [W]
Estimated power loss
at 460 V [W] 3) 4)
Weight,enclosure IP21, IP54 [kg]
4)
Efficiency
Output frequency
Heatsink overtemp. trip
Control card ambient trip
* High overload=160% torque during 60 s, Normal overload=110% torque during 60 s.
Table 4.4 Technical Specifications F8/F9 Frames, 380-500 Mains Supply 6x380-500 V AC, 12-Pulse
1) American Wire Gauge.
2) For fuse ratings, see 7.2.1 Fuses.
3) Typical power loss is at normal conditions and expected to be within
values are based on a typical motor efficiency (IE/IE3 border line). Lower efficiency motors add to the power loss in the frequency converter. If the
switching frequency is raised from nominal, the power losses rise significantly. LCP and typical control card power consumptions are included.
Options and customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for slots A and B each add
only 4 W.
4) Measured using 5 m screened motor cables at rated load and rated frequency.
®
VLT AutomationDrive FC 300 Design Guide 90-1200 kW
P250
HO NO
250 315
350 450
315 355
F8/F9
F8/F9
480 600
720 660
443 540
665 594
333 416
353 430
384 468
472 590
436 531
1) 4x90 (3/0)
]
1)
] 4x240 (4x500 mcm)
1) ] 2x185 (2x350 mcm)
5164 6790
4822 6082
MG34S202 - Rev. 2013-08-19
P315 P355
HO NO HO
315 355 355
450 500 500
355 400 400
F8/F9 F8/F9
F8/F9 F8/F9
600 658 658
900 724 987
540 590 590
810 649 885
416 456 456
430 470 470
468 511 511
590 647 647
531 580 580
4x90 (3/0) 4x240 (500 mcm)
4x240 (4x500 mcm) 4x240 (4x500 mcm)
2x185 (2x350 mcm) 2x185 (2x350 mcm)
700
6960 7701 7691
6345 6953 6944
447/669
0.98
0-590 Hz
110 °C
85 °C
± 15% (tolerance relates to variety in voltage and cable conditions.) These
P400
NO HO NO
400 400 450
600 550 600
500 500 530
F8/F9
F8/F9
745 695 800
820 1043 880
678 678 730
746 1017 803
516 482 554
540 540 582
587 587 632
733 684 787
667 667 718
4x240 (500 mcm)
4x240 (4x500 mcm)
2x185 (2x350 mcm)
8879 8178 9670
8089 8085 8803
59
4 4
