Mechanical Installation

6.2.6 Terminal Locations - Frame Size F, 12-Pulse

The 12-Pulse F-frame enclosures have 6 different sizes. The F8, F10, and F12 consist of an inverter cabinet on the right and a
rectifier cabinet on the left. The F9, F11, and F13 are F8, F10, and F12 units with an additional options cabinet to the left of
the rectifier.
Terminal Locations - Inverter and Rectifier Frame Size F8 and F9
1
Illustration 6.74 Terminal Locations - Inverter and Rectifier Cabinet - F8 and F9. Gland Plate is 42 mm below .0 Level.
1
Left Side View
2
Front View
3
Right Side View
4
Earth/Ground Bar
Table 6.41 Legend to Illustration 6.77
®
VLT
AutomationDrive FC 300 Design Guide 90-1200 kW
239.6 [ 9.43 ]
R2/L12
91-1
S2/L22
92-1
T2/L32
160.0 [ 6.30 ]
R1/L11
91
S1/L21
92
T1/L31 93
56.6 [ 2.23 ]
0.0 [ 0.00 ]
MG34S202 - Rev. 2013-08-19
2
U/T1 96
V/T2 97
W/T3 98
93-1
4
3
6
143
6
