How to Order

4 How to Order

4.1 Ordering Form

4.1.1 Drive Configurator
It is possible to design a frequency converter according to
the application requirements by using the ordering
number system.
Order the frequency converter as either standard or with
integral options by sending a type code string describing
the product a to the local Danfoss sales office, i.e.:
FC-102P18KT4E21H1XGCXXXSXXXXAGBKCXXXXDX
The meaning of the characters in the string can be located
in the pages containing the ordering numbers in chapter 3
Selection. In the example above, a Profibus LON works
option and a General purpose I/O option is included in the
frequency converter.
Ordering numbers for frequency converter standard
variants can also be located in chapter 4 How to Order.
Configure the right frequency converter for the right
application and generate the type code string in the
Internet-based Drive Configurator. The Drive Configurator
automatically generates an 8-digit sales number to be
delivered to the local sales office.
Furthermore, establish a project list with several products
and send it to a Danfoss sales representative.
The Drive Configurator can be found on the global
Internet site: www.danfoss.com/drives.
Example of Drive Configurator interface set-up:
The numbers shown in the boxes refer to the letter/figure
number of the Type Code String - read from left to right.
Product groups 1-3
Frequency converter series 4-6
Power rating 8-10
Phases 11
Mains Voltage 12
Enclosure 13-15
Enclosure type
Enclosure class
Control supply voltage
Hardware configuration
RFI filter 16-17
Brake 18
Display (LCP) 19

MG11BC02

Design Guide
Coating PCB
Mains option
Adaptation A
Adaptation B
Software release
Software language
A options
B options
C0 options, MCO
C1 options
C option software
D options
Table 4.1 Example of Drive Configurator Interface Set-up
Danfoss A/S © Rev. 06/2014 All rights reserved.
20
21
22
23
24-27
28
29-30
31-32
33-34
35
36-37
38-39
4 4
