Mechanical Installation
Illustration 6.70 Terminal Locations - Regeneration Terminals
for F2 and F4
Terminal Locations - Rectifier (F1, F2, F3 and F4)
6 6
6
Illustration 6.71 Terminal Locations - Rectifier. Gland Plate is 42 mm below .0 Level.
1 Left Side View
2 Front View
3 Right Side View
4 Loadshare Terminal (-)
5 Earth/Ground Bar
6 Loadshare Terminal (+)
Table 6.37 Legend to Illustration 6.71
140
VLT
1
435.5 [17.15]
343.1 [13.51]
193.9 [7.64]
70.4 [2.77]
0.0 [0.00]
®
AutomationDrive FC 300 Design Guide 90-1200 kW
DC '-'
1739.1
1203.2
1163.2
1694.1
DC '+'
1654.1
1098.1
2
CH22 CH22 CH22 CH22 CH22 CH22
CTI25MB CTI25MB
FASTENER TORQUE: M8 9.6 Nm (7 FT-LB) FASTENER TORQUE: M10 19 Nm (14 FT-LB)
R/L1 91 S/L2 92 T/L3 93
FASTENER TORQUE: M10 19 Nm (14 FT-LB) FASTENER TORQUE: M10 19 Nm (14 FT-LB)
DC 89 DC 89
MG34S202 - Rev. 2013-08-19
3
5
LOAD SHARE LOCATION
DIM F1/F2
A 380.5 [14.98] 29.4 [1.16]
B 432.5 [17.03] 81.4 [3.20]
4
F3/F4
