Electrical Installation
Terminal Locations - D5h
Take the following position of the terminals into consideration when designing the cable access.
A-A
Illustration 7.7 Terminal Locations, D5h with Disconnect Option
1 Mains Terminals
2 Brake Terminals
Table 7.5 Legend to Illustration 7.7
®
VLT AutomationDrive FC 300 Design Guide 90-1200 kW
A B
1
221
[ 8.7 ]
148
[ 5.8 ]
118
[ 4.6 ]
4
0
0 [ ] B
A
U
V
W
S
R
T
3 Motor Terminals
4 Earth/Ground Terminals
MG34S202 - Rev. 2013-08-19
2
227
9 [ ]
196
[ 7.7 ]
3
90
[ 3.6 ]
B-B
7
165
7
