(1)-43 Range setting
Select the range of the current (power) to measure.
Setting
Current
Power
Do not change the range through the GL100-WL after setting the range of the GL240.
The displayed values of the GL240 may not match the measured values.
(1)-44 EU setting
This is used to unit-convert the measurement signal.
Refer to "<Setting example: For voltage input>" in "(1)-5 EU (Scaling settings)" in "3.4 Setting Menus".
Even if the scaling setting is applied to the original measured value of CH, the accumulated power is not
reflected in the accumulated power CH.
(1)-45 Other setting
The following settings can be performed.
Setting
Annotation text string
Program Inter-CH
calculation
Span setting
Waveform color setting
Line Thickness Setting
Trace
Voltage value
(Power only)
Power factor (Power only) Set the power factor to calculate the power within the range of 0.30 to1.00.
Auto zero adjustment
Zero adjustment reset
Zero point voltage value
50, 100, 200A
(20, 50, 100kW) It is linked to the current range.
Set the annotation (comment) displayed in the CH.
Set the contents of Program Inter-CH calculation.
Four arithmetic operations (addition (+), subtraction (-), multiplication (x), division (÷)) can be used for
the Program Inter-CH calculation.
* For detaols, refer to "<Inter-CH Op Settings>" in "(1)-6 Misc." in "3.4 Setting Menus".
Set the upper and lower limits of the span which the waveform is displayed.
0 to 31 for each of red, green, blue (RGB)
1 to 8 dots
This is used to set the waveform display.
Set the measurement voltage value to calculate the power within the range of 90 to 264V.
The current input current value is calculated as a zero point current value.
Reset the zero point current value.
* This function is not applied to power measurement.
Display the zero point current value.
* This function is not applied to power measurement.
CHAPTER 3 Settings and Measurement
Description
Description
3-41
