(3)-3 Repeated capturing
This is used to enable or disable the repeat function to conduct repeated capturing.
Selection item
Off
On
(3)-4 Alarm level settings
This is used to set alarm generation conditions, output destination, etc.
When the conditions specified here are met, the alarm output terminal (for which an output destination number
must be specified for each channel) outputs an alarm.
For the CH condition settings, refer to "Trigger Level Settings/Alarm Level Settings" described below.
(3)-5 Alarm hold
If "Alarm retention" is selected here, once the established conditions have been met the alarm status will not
be cleared, regardless of whether or not the conditions continue to be met (Pressing the [CURSOR] key will
clear it.)
(Press the [CURSOR] key to cancel it).
(3)-6 Send burnout alarm
The alarm is output from the alarm output terminal by selecting "Sent" when the burnout occurs (Refer to "(6)-7
Burnout) described below.
The repeat function is disabled.
The repeat function is enabled.
After one capture is ended, the next capture is started (If the start side source setting is not
Off, the GL240 waits for a trigger).
Also, when setting to the specified time, the date and time must be set. However, when the
repeat function is enabled (On), the specified time is changed to the time display. It occurs
the trigger once a day.
CHAPTER 3 Settings and Measurement
Description
3-51
