4.3 Accessories/Optional Accessories

Control Software

Item
Compatible operating system
Function
Number of groups
Number of CHs per 1 group
Maximum number of channels
Settings
Captured data
Display
Display modes
File conversion
Monitor functions
Statistic/History
Report function
E-mail function

Accessories

Item
Quick Start Guide
CD-ROM
AC adapter
Ferrite core

Wireless Unit B-568 (Option)

Item
Communication system
Installation
Wireless LAN standard
Number of connected GL100-WL
Function
Windows10/Windows8.1/Windows8/Windows7/Windows Vista
Main unit control, realtime data capture, data conversion
4 groups MAX
Up to number of connected module
1000 ch maximun
AMP settings, capture settings, trigger/alarm settings, report settings, others
Realtime data (CSV, GBD Binary)
Data in Internal memory (SD1) or SD memory card (SD2) (CSV, GBD binary)
Analog waveforms, logic waveforms, pulse waveforms, digital values
Y-T View, Digital View, X-Y View between Cursors (only during replay), Integrated
bar graph display
Between cursors, All data
Alarm monitor enables sending of email to the specified address
Displays maximum, minimum and average values during measurement
Enables creation of daily or monthly files
The e-mail is sent to the specified address when the alarm monitor is performed.
GL240-UM-8xx: 1
GL240-CDM0xM (User's Manual, Application): 1
100 to 240 VAC, 50/60 Hz, Power supply cord for each area: 1
This is used to attach to the USB cable: 1
Wireless LAN
Insert into the SD CARD2 slot
* When the wireless unit is inserted, the SD memory card cannot be inserted into
the SD CARD2 slot.
IEEE802.11b/g/n
Up to 1 units
Communication range: Approx. 40 m
* Communication range depends on the obstacles and the surrounding
environmental conditions.
Access point : Control of wireless sensor and data capture
Station : Control from PC and Data transfer to PC
Control from Smartphone or tablet, and Data transfer
Common to access point and station:
WPS : Push button method / PIN method
Encryption function : WEP64, WEP128, WPA-PSK/WPA 2-PSK, TKIP/AES
CHAPTER 4 Specification
Description
Description
Description
4-7
