CHAPTER 3 Settings and Measurement
Download of device file
The captured data in the internal memory (SD1) or SD memory card (SD2) of the GL240 can be downloaded
to the PC.
To display the FTP site in the Explorer from the figure above, press the Alt key and click the "View" and then
click the "Open FTP side with Explorer". The foillowing screen is displayed.
<About the FTP server function>
When an Internet Explorer FTP connection is used, login is automatically performed using an anonymous
account and the files become read-only files.
The following operations cannot be performed for read-pnly files:
• Upload file
• Delete file/folder
• Create file/folder
• Change file name/folder name
To enable data to be written to the GL240, the login account name must be changed.
Please use the following table as a guide.
Account name
GL240
gl240
Anonymous
3-92
Password
None
None
Any
Restrictions
None
None
Read-only
