(3) Time Zone
Sets the time zone of an area in which the GL240 is to be used. (Japan: +09:00)
(4) Synchronized Time
Sets the time at which the GL240 synchronizes to the time server. When the specified time comes, time
synchronization operation is performed using a method specified in Synchronization Mode.
(5) Adjust Mode
Synchronize at once, Synchronize gradually
Sets the mode in which the GL240 synchronizes to the time server.
Synchronize at once: When the synchronization time comes, the GL240 synchronizes to the time server at once.
Synchronize gradually : Even when the synchronization time comes, the GL240 does not synchronize at once.
(6) Connection Test
Performs connection test to the time server.
When the connection test is performed, a message is displayed.
If connection cannot be established, check the settings and perform the connection test again.
* If the connection test is passed, the following message is displayed.
Synchronization is not performed if the time difference with the time server is 500 ms or less.
(6)-11 Language
Set the display language (9 languages of Japanese, English (US), English (UK), French, German, Chinese,
Korean, Spanish and Russian).
(6)-12 Return to default settings
Returns all the settings to the factory defaults. When initialized, setting conditions to return to the factory
default settings.
(6)-13 Information
Displays system information.
(6)-14 Demo Waveform Mode
This parameter displays demo waveforms without analog signal input.
Selection item
Off
On
It synchronizes to the time of the time server gradually.
The rate of adjustment is about 43 seconds per day
(equivalent to around 10 ms per 20 seconds).
The demo waveform is not displayed.
The demo waveform is displayed.
