3.5 WEB Server Function

Web browser allows operating and monitoring GL240 through an optional wireless LAN unit.
• Supported Web browsers
• Microsoft Internet Explorer 11 or later
• Firefox 1.5 or later
• Available functions using a Web browser
• Operating GL240
• Monitoring GL240 display screen
• Enlarging GL240 display screen
• Linking to FTP
• Linking to our Web site
• Setting the URL
The URL (Uniform Resource Locator) must be correctly set according to your network environment.
When the port number is changed, enter the following:
http://(IPaddress): Port number/index.html
• http ...................... Protocol to access the server.
• IP address ........... Enter in the IP address of the GL240 to monitor.
• Port number ........ Specify the port number.
• Index.html .......... This is the file name. This file name is fixed to index.html.
•
The port number can be omitted. In this case, the port number is 80.
http://(IPaddress): 80/index.html
•
It is not possible to simultaneously WEB connection from multiple browsers. Please use a single browser
for one GL240 main unit.
<Procedure>
1. Open the Web browser.
HTTP (Hyper Text Transfer Protocol)
The port number is the number set to the GL240 or router, etc.
CHAPTER 3 Settings and Measurement
3-89
