(8) START/STOP (USB Drive Mode)
USB Drive Mode Operation Procedure
In the "USB Drive Mode", the internal memory (SD1) and SD memory card (SD2) can be check on a PC as
an external storage device.
When two SD memory cards are inserted into the SD CARD 2 (SD2) respectively, they are recognized as
two external storage media.
Since the SD memory card is recognized as a removal disk, this mode facilitates file manipulation such as
transfer and deletion.
1. Use a USB cable to connect the GL240 and a PC.
2. While pressing the GL240 [START/STOP] key, turn the power ON.
3. The external storage media is recognized by the PC and data exchange becomes possible.
* In USB Drive Mode, the display becomes as follows:
•
To exit USB Drive Mode, turn off and on the power again.
•
In USB Drive Mode, no operation including data capture and data replay is available.
This key performs the following two operations:
<Starts/stops capture>
• During Free Running, starts capture.
• During capture, stops capture.
