<Operation procedure>
(1) Select the station, and then execute the wireless LAN restart.
The "Wireless LAN restarting" is displayed and the restart is executed by the station setting.
(2) Set the SSID.
Enter in accordance with the procedure of "(9) Text input" described below.
Also, to enter the SSID, follow the procedure in "(9) Text input". Also, after searching the SSID in the
following (3), you can select it from the list.
(3) Search the SSID.
Press the key. The searched SSID list is displayed after searching the SSID.
In Step (2), when the SSID is selected from this list, the SSID will be automatically reflected.
(4) Set the automatic setting (WPS).
The wireless LAN is automatically set in the WPS system by pressing the
(5) Set the encryption method. (In the case of manual setting)
WEP or WPA-PSK/WPA2-PSK settings can be performed. When this setting is selected, the "WEP key"
is displayed. Enter in accordance with the procedure of "(9) Text input" described below.
(6) Set the wireless standard 11n.
When the IEEE802.11n is used, set to "ON".
(7) When the above settings are finished, press the
The settings are saved.
(8) The wireless LAN is enabled by executing the "Connect/Disconnect" in the "Other settings".
(5)-3 Other setting
When connecting to the wireless LAN after setting the station, by pressing the [Connect/Disconnect] key, the
"Restart TCP-IP" is displayed and then the connection is established.
To disconnect the wireless LAN during the connection, press the [Connect/Disconnect] key again.
When you want to change the connection conditions, perform the "ST-IP setting".
• When the "IP Addr Auto Acq." is used, select the "On".
• When the "IP Addr Auto Acq." Is not used, select the "Off" and then set the IP address, Subnet masuk, and
Port number, etc.
After the above setting, press the
displayed and the setting operation is completed.
key to execute the "Apply settings".
Effective display
Key of "Apply settings" in the "ST-IP setting". The "Restart TCP-IP" is
CHAPTER 3 Settings and Measurement
key.
3-59
