CHAPTER 3 Settings and Measurement
(1)-36 EU setting
The unit of Illumination/ultraviolet is converted.
Refer to "(1)-5 EU (Scaling settings)" in "3.4 Setting Menus".
There is no "EU Function" for accumulated illuminance and accumulated ultraviolet.
Even if the scaling setting is applied to the original measured value of CH, the accumulated illuminance is
not reflected in the accumulated illuminance CH.
(1)-37 Other setting
The following settings can be performed.
Setting
Annotation text string
Program Inter-CH
calculation
Span setting
Waveform color setting
Line Thickness Setting
Trace
Auto zero adjustment
Zero adjustment reset
Zero point voltage value
3-38
Set the annotation (comment) displayed in the CH.
Set the contents of Program Inter-CH calculation.
Four arithmetic operations (addition (+), subtraction (-), multiplication (x), division (÷)) can be used for
the Program Inter-CH calculation.
* For details, refer to "<Inter-CH Op Settings>" in "(1)-6 Misc." in "3.4 Setting Menus".
Set the upper and lower limits of the span which the waveform is displayed.
0 to 31 for each of red, green, blue (RGB)
1 to 8 dots
This is used to set the waveform display.
The current input value is calculated as a zero point.
Reset the zero point.
Display the zero point.
Description
