CHAPTER 2 Checks and Preparation

2.10 Using the Battery Pack (B-569 : Option)

•
The B-569 (optional) is the only battery type that can be used with the GL240.
•
Refer to "4.3 Accessories/Optional Accessories" for information on the battery run time.
•
The operating temperature ranges of the GL240 with a battery pack mounted are as follows:
Running on battery
Battery being charged
Mounting the Battery Pack
(1) While lightly pushing the grip of the battery cover, slid the cover in the direction indicated by the arrow.
(2) Attach the battery pack (B-569).
2
Battery pack
(3) Attach the battery cover.
2-16
: 0 to 40°C
: 15 to 35°C
Grip
1
