CHAPTER 2 Checks and Preparation

This chapter explains how to check the main module's external casing and accessories, and how to prepare the
main module for operation.
PRODUCT SUMMARY
2.1 Checking the Outer Casing
2.2 Checking the Accessories
2.3 Nomenclature and Functions
2.4 Connecting the Power Cable and Turning on the
Power
2.5 Connecting the Signal Input Cables
2.6 Logic Alarm Cable Connection and Functions
2.7 Mounting the SD Memory Card
2.8 Installing the Wireless LAN Unit (B-568: Option)
2.9 Connecting to a PC
2.10 Using the Battery Pack (B-569 : Option)
2.11 Connecting the Humidity Sensor (Optional)
2.12 Precautions to Observe When Performing
Measurement
2.13 Noise Countermeasures
2.14 Setting the Date and Time
CHAPTER 2 Checks and Preparation
2-1
