Chapter 5 Configuring the EM720
EM720 Power Quality and Revenue Meter
Data Log #1
Data Log #1 is configured for recording 1-second phase
voltages, currents total harmonics, and total powers. The
list of parameters is shown in the following table.
No.
1 V1/V12
2 V2/V23
3 V3/V31
4 I1
5 I2
6 I3
7 Total kW
8 Total kvar
9 Total kVA
10 Total PF
11 V1/V12 THD
12 V2/V23 THD
13 V3/V31 THD
14 I1 THD
15 I2 THD
16 I3 THD
Data Log #2
Data Log #2 is configured for recording present voltage,
current and power demands, engineering (not billing)
energy counters, and 1-second neutral current and line
frequency. The list of parameters is shown in the following
table.
No.
1 V1/V12 Demand
2 V2/V23 Demand
3 V3/V31 Demand
4 I1 Demand
5 I2 Demand
6 I3 Demand
7 kW Import Sliding Demand
8 kvar Import Sliding Demand
9 KVA Sliding Demand
10 kWh Import
11 kWh Export
12 kvarh Import
13 kvarh Export
14 kVAh
15 In
16 Frequency
Data Log #13
Data Log #13 is linked to the Fault recorder and is
configured for fast 1/2-cycle RMS profiling of fault events.
You can freely manipulate this file, as you want. See
Configuring Recorders
Data Log #1
Parameter
Data Log #2
Parameter
