Appendix B Setpoint Parameters

Appendix B Setpoint Parameters
Setpoint Triggers
Setpoint Actions
NONE
SET EVENT FLAG
CLEAR EVENT FLAG
OPERATE RELAY
RELEASE RELAY
INCREMENT COUNTER
CLEAR COUNTER
RESET ALL COUNTERS
RESET DEMANDS
RESET DEMANDS
RESET DEMANDS
RESET DEMANDS
RESET DEMANDS
RESET DEMANDS
RESET TOU DEMANDS
CLEAR MIN/MAX LOG
EVENT LOG
EVENT LOG
EVENT LOG
DATA LOG
WAVEFORM LOG
192
For setpoint triggers, see Appendix A Parameters for
Monitoring and Logging.
The available setpoint actions are listed in the following
table.
Setpoint Actions
Action Target
1-8
1-8
1-4
1-4
1-8
1-8
ALL
POWER
VOLT/AMP
VOLT
AMP
HRM
OPER
RELS
ANY
1-14
1-2
Description
No action
Set user event flag 1-8
Clear user event flag 1-8
Operate relay RO1-RO4
Release latched relay RO1-RO4
Increment counter 1-8
Clear counter 1-8
Clear all counters
Reset all engineering maximum demands
Reset engineering maximum power demands
Reset maximum volts and ampere demand
Reset maximum volt demand registers
Reset maximum ampere demand registers
Reset maximum harmonic demand registers
Reset billing/TOU maximum demands (end of billing
period)
Clear Min/Max log
Event log on setpoint operated
Event log on setpoint released
Event log on any setpoint transition
Conventional data log 1-14
Waveform Log 1-2
