Appendix E EN50160 Evaluation and Recording
Indicatives Values
Resources
EM720 Power Quality and Revenue Meter
For the remaining characteristics of the voltage, by their
unpredictable nature, the standard gives only indicative
values, which are
information on the order of magnitude which can be
expected.
The following table gives the characteristics for which
indicative values have been specified by the standard.
Voltage Characteristic
Voltage dips
Short interruptions
Long interruptions
Temporary overvoltages
Transient overvoltages
CENELEC publications:
EN 50160:1999 Voltage characteristics of electricity
supplied by public distribution systems
IEC publications:
IEC 61000-4-7:2002
(EMC) – Part 4-7 Testing and measurement techniques
– General guide on harmonics and interharmonics
measurements and instrumentation, for power supply
systems and equipment connected thereto,
IEC 61000-4-15:2003 Electromagnetic compatibility
(EMC) – Part 4 Testing and measurement techniques –
Section 15: Flickermeter – Functional and design
specifications
IEC 61000-4-30:2003 Electromagnetic compatibility
(EMC) – Part
techniques – Power quality measurement methods
Eurelectric (Union of the Electricity Industry) publications:
Application guide to the European Standard EN 50160
on Voltage characteristics of electricity supplied by
public distribution systems, Ref: 23002 Ren9530, July
1995
Measurement guide for voltage characteristics, Ref:
23002 Ren9531, July 1995
intended to provide
Indicative values
Less than 1 s, 60% depth
70% less than 1 s
10 to 50% less than 3 min
Less than 1.5 kV RMS
Less than 6 kV peak
Electromagnetic
4-30 Testing and
users with
Observation
period
Year
Year
Year
Year
Year
compatibility
measurement
