Chapter 5 Configuring the EM720
Parameter
Operation
mode
Polarity
Retentive
mode
Pulse width
Pulse source
Pulse rate,
kWh/Pulse
80
Options Default
UNLATHCED UNLATCHED Unlatched mode: the relay goes to its active
LATCHED
PULSE
KYZ
NORMAL (N.O.) NORMAL
INVERTING (N.C.)
NO NO
YES
20-1000 ms 100 ms
NONE NONE
kWh IMP
kWh EXP
kvarh IMP
kvarh EXP
kvarh TOT
kVAh
0.1-1000.0 1.0
kWh/Pulse
Description
state when the control setpoint is in active
(operated) state, and returns to its non-active
state when the setpoint is released.
Latched mode: the relay goes to its active state
when the control setpoint goes to active state
and remains in the active state until it is
returned to its non-active state by a local or
remote command.
Pulse mode: the relay goes to its active state
for the specified time, goes to non-active state
for the specified time and remains in the non-
active state.
KYZ mode: the relay generates transition
pulses. The relay output state is changed upon
each command and remains in this state until
the next command.
Normal polarity: the relay is normally de-
energized in its non-active state and is
energized in its active (operated) state.
Inverting polarity: the relay is normally
energized in its non-active state and is de-
energized in its active (operated) state. It is
called failsafe relay operation.
Applicable for latched relays only.
Non-retentive mode: the relay always returns to
its non-active state upon power up.
Retentive mode: the relay status is restored to
what it was prior to loss of power.
The actual pulse width is a multiple of the 1/2-
cycle time rounded to the nearest bigger value.
The pause time between pulses is equal to the
pulse width.
Links a pulse relay to the internal energy pulse
source. The relay must be set into either pulse,
or KYZ mode.
Defines the pulse weight in kWh units per pulse.
