Chapter 5 Configuring the EM720
Repetition Rate
Pst Period
THD, up to order
Harmonics, up to
order
Evaluation
THD, up to order
Interharmonics,
up to order
Evaluation
1st Signaling
Frequency
2nd Signaling
Frequency
3rd Signaling
Frequency
4th Signaling
Frequency

Clearing EN50160 Evaluation Counters

114
Option Range
1-10
1-10 min
25-50
25-50
Disabled,
Enabled
25-50
25-50
Disabled,
Enabled
110-3000
Hz
110-3000
Hz
110-3000
Hz
110-3000
Hz
See Resetting Accumulators and Log Files
how to clear the present contents of the EN50160
evaluation
evaluation.
Configuring the EN50160 Recorders
Default
Rapid Voltage Changes
1 Defines the maximum repetition rate in
variations per hour (equal or less than) for
rapid voltage changes. Voltage changes at
higher rates are not classified since they
will be subject for flicker.
Flicker
10 min Defines the period of time for the short-
term flicker evaluation. The standard
setting of 10 minutes can be temporarily
changed in the device for testing purposes.
Harmonic Voltage
40 Defines the highest harmonic order included
in the THD evaluation.
25 Defines the highest harmonic order for
evaluation of the harmonic voltages.
Interharmonic Voltage
Disabled Enables the evaluation of the interharmonic
voltages
40 Defines the highest interharmonic order
included in the THD evaluation.
25 Defines the highest harmonic order for
evaluation of the interharmonic voltages.
Mains Signaling Voltage
Disabled Enables the evaluation of the mains
signaling voltages
183.0 Hz Specifies the mains signaling frequency for
the compliance evaluation
191.0 Hz Specifies the mains signaling frequency for
the compliance evaluation
217.0 Hz Specifies the mains signaling frequency for
the compliance evaluation
317.0 Hz Specifies the mains signaling frequency for
the compliance evaluation
counters before
