Chapter 7 Monitoring Meters
Viewing a Data Table
Viewing Data Trend
EM720 Power Quality and Revenue Meter
If you check "Do not stop on errors", polling is resumed
automatically when
otherwise polling stops until you restart it manually.
Changing the Data View
PAS displays data in either a single record or multi-record
view. To change the view, click on the Data Monitor
window with the right mouse button and select either
Wrap to see a single record, or UnWrap to go to the multi-
record view.
Adjusting the Number of Rows in a Multi-Record
View
Click the window with the right mouse button, select
Options, adjust the number of records you want to see in
the window, and then click OK. When the number of
retrieved records exceeds the number of rows in the
window, the window scrolls up so that older records are
erased.
Selecting Primary and Secondary Units
Voltages and currents can be displayed in primary or
secondary units. To select primary or secondary units for
your data views, click on the monitor window with the
right mouse button, select Options, select the desired
units for voltages and currents, and then click OK.
To view a data trend, click on the
toolbar. To change the time range for your graph, click on
the button on the local toolbar, and then select the
desired date and time range.
Viewing Real-time Data
a communication
button on the local
error occurs,
