Chapter 2 Operating the EM720
Chapter 2 Operating the EM720
Controls and Indicators
Push Buttons
Graphical Display Indicators
Energy Pulse LED Indicators
14
The EM720 provides two sealable push buttons that do not
have labels. They allow you to scroll through the multi-
page display screens for local meter reading, to inspect or
change meter setup parameters, and to control display
operations.
See
Navigation Buttons
and functionality.
The EM720 graphical display is used both for displaying
billing and instrumentation data, and for indication of the
present tariff rate and important diagnostic information.
See
Status Indicators
graphical status indicators.
The EM720 is provided with two red LED indicators labeled
as "kWh" and "kvarh" that flash when a load is applied to
the meter.
EM720 Power Quality and Revenue Meter
in Chapter 3 for buttons location
in Chapter 3 for information on
