Appendix A Parameters for Monitoring and Logging
Designation
HRM TOT POW
kW H01
kvar H01
kVA H01
PF H01
FLICKER
V1 Pst
V2 Pst
V3 Pst
V1 Plt
V2 Plt
V3 Plt
MIN PHASE
V1 MIN
V2 MIN
V3 MIN
I1 MIN
I2 MIN
I3 MIN
kW L1 MIN
kW L2 MIN
kW L3 MIN
kvar L1 MIN
kvar L2 MIN
kvar L3 MIN
kVA L1 MIN
kVA L2 MIN
kVA L3 MIN
PF L1 MIN
PF L2 MIN
PF L3 MIN
V1 THD MIN
V2 THD MIN
V3 THD MIN
I1 THD MIN
I2 THD MIN
I3 THD MIN
I1 KF MIN
I2 KF MIN
I3 KF MIN
I1 TDD MIN
I2 TDD MIN
I3 TDD MIN
V12 MIN
V23 MIN
V31 MIN
MIN TOTAL
kW MIN
kvar MIN
kVA MIN
PF MIN
PF LAG MIN
PF LEAD MIN
MIN AUX
I4 MIN
EM720 Power Quality and Revenue Meter
Fundamental Total Power Values
Total fundamental kW
Total fundamental kvar
Total fundamental kVA
Total fundamental PF
Flicker
1
V1 short-term (10 min) flicker severity
V2 short-term (10 min) flicker severity
V3 short-term (10 min) flicker severity
V1 long-term (2 hours) flicker severity
V2 long-term (2 hours) flicker severity
V3 long-term (2 hours) flicker severity
Minimum 1-Cycle Phase Values
V1 voltage
V2 voltage
V3 voltage
I1 current
I2 current
I3 current
kW L1
kW L2
kW L3
kvar L1
kvar L2
kvar L3
kVA L1
kVA L2
kVA L3
Power factor L1
Power factor L2
Power factor L3
V1 voltage THD
V2 voltage THD
V3 voltage THD
I1 current THD
I2 current THD
I3 current THD
I1 K-Factor
I2 K-Factor
I3 K-Factor
I1 current TDD
I2 current TDD
I3 current TDD
V12 voltage
V23 voltage
V31 voltage
Minimum 1-Cycle Total Values
Total kW
Total kvar
Total kVA
Total PF
Total PF lag
Total PF lead
Minimum 1-Cycle Auxiliary Values
I4 current
Description
