Satec Expertmeter EM720 Operation Manual page 187

Appendix A Parameters for Monitoring and Logging
Designation
I1 DMD MAX
I2 DMD MAX
I3 DMD MAX
kW IMP SD MAX
kvar IMP SD MAX
kVA IMP SD MAX
kvar IMP SD MAX
kvar EXP SD MAX
I4 DMD MAX
MAX HRM DMD
V1 THD DMD MAX
V2 THD DMD MAX
V3 THD DMD MAX
I1 THD DMD MAX
I2 THD DMD MAX
I3 THD DMD MAX
I4 THD DMD MAX
I1 TDD DMD MAX
I2 TDD DMD MAX
I3 TDD DMD MAX
I4 TDD DMD MAX
MAX SUMMARY DMD
REG1 MD
REG2 MD
...
REG10 MD
REG1 CMD
REG2 CMD
...
REG10 CMD
ANALOG INPUTS
AI1
AI2
...
AI8
AI RAW
AI1 RAW
AI2 RAW
...
AI8 RAW
AO RAW
AO1
AO2
...
AO8
TOU PRMS
ACTIVE TARIFF
ACTIVE PROFILE
TOU REG1
REG1 TRF1
REG1 TRF2
...
REG1 TRF8
TOU REG2
REG2 TRF1
EM720 Power Quality and Revenue Meter
I1 maximum ampere demand
I2 maximum ampere demand
I3 maximum ampere demand
Maximum kW import sliding demand
Maximum kvar import sliding demand
Maximum kVA sliding demand
Maximum kW export sliding demand
Maximum kvar export sliding demand
I4 maximum ampere demand
Maximum Harmonic Demands
V1/V12 THD demand
1
V2/V23 THD demand
1
V3/V31 THD demand
1
I1 THD demand
I2 THD demand
I3 THD demand
I4 THD demand
I1 TDD demand
I2 TDD demand
I3 TDD demand
I4 TDD demand
Billing Summary (Total) Maximum Demands
Summary register #1 maximum demand
Summary register #2 maximum demand
...
Summary register #10 maximum demand
Summary register #1 cumulative maximum demand
Summary register #2 cumulative maximum demand
...
Summary register #10 cumulative maximum demand
Scaled Analog Inputs (Engineering Units)
Analog input AI1
Analog input AI2
Analog input AI8
Raw Analog Inputs (A/D Units)
Analog input AI1
Analog input AI2
Analog input AI8
Raw Analog Outputs (A/D Units)
Analog output AO1
Analog output AO2
Analog output AO8
TOU Parameters
Active TOU tariff
Active TOU profile
Billing TOU Energy Register #1
Tariff #1 register
Tariff #2 register
...
Tariff #8 register
Billing TOU Energy Register #2
Tariff #1 register
Description
