Chapter 8 Retrieving Recorded Data
Running the Scheduler on Demand
Reviewing Upload Problems

Retrieving EN50160 Statistics Files

Using the Upload Scheduler
Retrieving EN50160 Statistics Files on Demand
Retrieving the EN50160 Online Statistics

Viewing Historical Data On-line

EM720 Power Quality and Revenue Meter
You can run the scheduler at any time outside the
schedule by checking the Start Now box at right. This is a
one-time action. After uploading is completed, the Upload
Scheduler un-checks this box automatically.
When the Upload Scheduler fails to retrieve data from the
device, or some data is missing, or another problem
occurs, it puts an error message to the log file. To review
this file, select System Log from the View menu.
The EN50160 statistics files and present contents of the
EN50160 evaluation counters can be retrieved by PAS and
stored to a database for later analysis.
The PAS Upload Scheduler automatically retrieves the
EN50160 statistics files on a daily or weekly basis
depending on the EN50160 evaluation period selected in
your device.
Select the Daily or Weekly schedule for the EN50160
statistics files when configuring the upload schedule (see
Using the Upload Scheduler). Check the Data log #9 and
#10 boxes in the Select Logs dialog box for uploading the
EN50160 Compliance Statistics and EN50160 Harmonics
Survey files respectively.
To manually retrieve the EN50160 statistics files on
demand, select "Upload EN50160 Compliance Stats" from
the Logs menu and specify the database to which you
want the data to be stored.
To retrieve the present contents of the EN50160 statistics
counters accumulated since the beginning of the current
evaluation period, select "Upload EN50160 Online Stats"
from the Logs menu and specify the database to which
you want the data to be stored. The statistics records are
marked as online events.
See Viewing EN50160 Statistics Reports
EN50160 compliance report for the latest online statistics
stored in the database.
Sometimes, it is useful to review a particular piece of
historical data on-line at the time you expect new events
Retrieving EN50160 Statistics Files
on how to get the
143
