Appendix D EN50160 Statistics Log Files

Appendix D EN50160 Statistics Log
Files
EN50160 Compliance Statistics Log (Data Log #9)
Field No.
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
3
4
5
6
7
1
2
3
4
5
6
7
EM720 Power Quality and Revenue Meter
The following
parameters recorded by the device to the EN50160
statistics data log files. The second column shows data
abbreviations used in the PAS data log reports. Data log
file sections are highlighted in bold.
Designation
Nnv Number of non-valid 10-sec intervals
N Number of valid 10-sec intervals
N1 Number of incidents ±1%, N1
N2 Number of incidents +4%/-6%, N2
N1/N, % EN50160 compliance ratio, N1/N
N2/N, % EN50160 compliance ratio, N2/N
Freq Min Minimum frequency
Freq Max Maximum frequency
Nnv Number of non-valid 10-min intervals
N Number of valid 10-min intervals
N1 Number of polyphase incidents ±10%, N1
N2 Number of polyphase incidents +10/-15%, N2
N1/N, % EN50160 compliance ratio, N1/N
N2/N, % EN50160 compliance ratio, N2/N
V1 N1 Number of incidents ±10% on phase V1
V1 Min Minimum voltage on phase V1
V1 Max Maximum voltage on phase V1
V2 N1 Number of incidents ±10% on phase V2
V2 Min Minimum voltage on phase V2
V2 Max Maximum voltage on phase V2
V3 N1 Number of incidents ±10% on phase V3
V3 Min Minimum voltage on phase V3
V3 Max Maximum voltage on phase V3
N1 Number of polyphase incidents
V1 N1 Number of incidents on phase V1
V1 dV% Maximum voltage variation on phase V1, dV/Un%
V2 N1 Number of incidents on phase V2
V2 dV% Maximum voltage variation on phase V2, dV/Un%
V3 N1 Number of incidents on phase V3
V3 dV% Maximum voltage variation on phase V3, dV/Un%
Nnv Number of non-valid 10-min intervals
N Number of valid 10-min intervals
N1 Number of polyphase incidents Plt >1%, N1
N1/N, % EN50160 compliance ratio, N1/N
V1 N1 Number of incidents Plt > 1% on phase V1
V1 Plt Max Maximum Plt on phase V2
V2 N1 Number of incidents Plt > 1% on phase V2
tables list the
Description
Power Frequency
Supply Voltage Variations
Rapid Voltage Changes
Flicker
EN50160 evaluation
