Chapter 3 Using Front Display

Programming Mode

Navigation Buttons

Entering Numeric Values

S
S
S
E
L

Password Security

S
S
E
L
EM720 Power Quality and Revenue Meter
To enter programming mode from the data display, press
and hold the SELECT/ENTER button for more than 5
seconds.
The following table gives a summary of the button
operations in programming mode.
Button
SCROLL Short press
SELECT/ENTER Short press (less than
1 second) = SELECT
SELECT/ENTER Long press (1 to 2
seconds) = ENTER
Whenever a numeric value is to be changed, use a short
press on the SELECT/ENTER button to highlight a desired
digit, and then use the SCROLL button to change the value
of the highlighted digit. A highlighted digit appears in
inversed color. If you missed a digit, just continue moving
through the rest of digits until you reach the desired
place.
Once the number is set to the desired value, press and
hold the SELECT/ENTER button for 1-2 seconds to save
your new setting.
To reject your changes and restore the previous value,
use a short press on the SELECT/ENTER button to return
to the higher-level window.
The setup menus are secured by 8-digit user passwords.
Every time you enter programming mode, you are
prompted for a correct password. The meter is primarily
shipped with all passwords preset to 9 at the factory. See
Meter Security
meter security levels.
It is recommended that you change the factory set
passwords as fast as possible to protect you setups and
accumulated
Configuring Meter Passwords
change passwords in your meter.
Press
Scroll through a menu item list in a
highlighted window or increment a
highlighted digit in a numeric field
Highlight a menu window or a digit in a
numeric field
Store the changed item or perform an
action indicated in a highlighted window
in Chapter 2 for more information on the
data from unauthorized
Programming Mode
Operations
changes.
in Chapter 5 on how to
See
