Chapter 3 Using Front Display

Navigating in Data Display Mode

30
The function of each button changes depending on what
operating mode the display is in.
The SCROLL button operates once it's briefly pressed. It
has two functions:
• In data display mode, it scrolls through the display
pages.
• In programming mode, it scrolls through the menu
items and allows changing a selected digit when
entering numbers.
The SELECT/ENTER button normally operates once it's
released. The button function changes depending on the
time the button is pressed:
• In data display mode, when pressed briefly and
released, it scrolls through the display views; a long
press for more than 5 seconds switches to
programming mode.
• In programming mode, when pressed briefly and
released, it moves from one menu item to another;
a long press for one second selects a highlighted
menu item allowing to enter a submenu or to store
a changed item.
In data display
SELECT/ENTER buttons are briefly pressed together and
then released, the current display returns to the start
page; in some pages, an extended press for more than 5
seconds is used as a "shortcut" for immediate entering a
specific programming menu.
The following table gives a summary of the button
operations in data display mode.
Button
SCROLL
SELECT/ENTER
SCROLL + SELECT/ENTER
SCROLL + SELECT/ENTER
in the clock page
SCROLL + SELECT/ENTER
in selected pages
SELECT/ENTER
The EM720 provides 9 different multi-page data displays
listed in the following table.
Display Number Display Label
1
2
3
mode, when
Press
Short press Scroll through pages
Short press Scroll through displays
Short press Return to the start page within
a present display
Short press Enter to/Return from the test
display
Extended press Shortcut for entering a specific
menu in programming mode
Extended press Enter programming mode
BILL 0 Present (0) billing period data
BILL 1 Last (-1) billing period data
BILL 2 Second previous (-2) billing period
data
EM720 Power Quality and Revenue Meter
Display Operations
the SCROLL
Operations
Display Contents
and
