Satec Expertmeter EM720 Operation Manual page 117

Chapter 5 Configuring the EM720
Analog Input Object
Analog Input Change
Event Object
Number of BC to Generate
events
Binary Counter Object
Binary Counter Change
Event Object
Frozen Binary Counter
Object
16-bit AI Scaling
16-bit BC Scaling
Re-mapping Event Points
SBO Timeout
Time Sync Period
Multi Fragment Interval
EM720 Power Quality and Revenue Meter
Parameter
32-bit
32-bit –Flag
16-bit
16-bit –Flag
32-bit -Time
32-bit +Time
16-bit -Time
16-bit +Time
0-64
32-bit +Flag
32-bit –Flag
16-bit +Flag
16-bit –Flag
32-bit -Time
32-bit +Time
16-bit -Time
16-bit +Time
32-bit +Flag
32-bit –Flag
32-bit +Time
16-bit +Flag
16-bit –Flag
16-bit +Time
Disabled
Enabled
x1, x10,
x100, x1000
Disabled
Enabled
2-30 sec
1
0-86400 sec
2
50-500 ms
1
The Select Before Operate command causes the device to start a
timer. The following Operate command must be sent before the specified
timeout value expires.
2
The device requests time synchronization by bit 4 in the first octet
of the internal indication word being set to 1 when the time interval
specified by the Time Sync Period elapses. The master should
synchronize the time in the device by sending the Time and Date object
to clear this bit. The device does not send time synchronization requests
if the Time Sync Period is set to 0.
3
The total number of AI, BI and BC change event points may not
exceed 64. When you change the number of the change event
points in the device, all event setpoints are set to defaults (see
Configuring DNP Event Classes below).
Configuring Communication Protocols
Options Default
16-bit -Flag
16-bit +Time The default AI change event object
Binary Counters (BC)
0
3
32-bit -Flag
32-bit +Time The default BC change event
32-bit -Flag
DNP General Options
Enabled
x1
Disabled
10
86400
50
Description
The default AI object variation for
requests with qualifier code 06
when no specific variation is
requested
variation for requests with qualifier
code 06 when no specific variation
is requested
The total number of BC change
event points for monitoring
The default BC object variation for
requests with qualifier code 06
when no specific variation is
requested
object variation for requests with
qualifier code 06 when no specific
variation is requested
The default frozen BC object
variation for requests with qualifier
code 06 when no specific variation
is requested
Allows scaling 16-bit analog input
objects (see description below)
Allows scaling 16-bit binary
counter objects (see description
below)
Allows re-mapping event points
starting with point 0.
Defines the Select Before Operate
(SBO) timeout when using the
Control-Relay-Output-Block object
Defines the time interval between
periodic time synchronization
requests
Defines the time interval between
fragments of the response
message when it is fragmented
