Appendix C Billing and Load Profile Log Files

Appendix C Billing and Load Profile Log
Files
Field No.
1
2
3
4
5
6
7
8
9
10
Montly Billing Profile (Billing Period) Data Log (Data Log #15)
Field No.
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
EM720 Power Quality and Revenue Meter
The following tables show the record structure for the
monthly and daily billing data profile and energy load
profile log files.
The second column shows data abbreviations used in the
PAS data log reports. Data log file sections are highlighted
in bold.
Energy Load Profile Data Log (Data Log #12)
Designation
REG1
REG2
REG3
REG4
REG5
REG6
REG7
REG8
REG9
REG10
The number of parameters in a record is automatically
configured depending on the number of billing registers
for which you selected a source input in the Billing/TOU
Register setup.
Designation
REG1
TRF1
TRF2
TRF3
TRF4
TRF5
TRF6
TRF7
TRF8
REG10
TRF1
TRF2
TRF3
TRF4
TRF5
TRF6
TRF7
TRF8
Summary (total) energy register 1 reading
Summary (total) energy register 2 reading
Summary (total) energy register 3 reading
Summary (total) energy register 4 reading
Summary (total) energy register 5 reading
Summary (total) energy register 6 reading
Summary (total) energy register 7 reading
Summary (total) energy register 8 reading
Summary (total) energy register 9 reading
Summary (total) energy register 10 reading
Energy Register #1
Summary (total) energy reading
Tariff #1 energy reading
Tariff #2 energy reading
Tariff #3 energy reading
Tariff #4 energy reading
Tariff #5 energy reading
Tariff #6 energy reading
Tariff #7 energy reading
Tariff #8 energy reading
Energy Register #10
Summary (total) energy reading
Tariff #1 energy reading
Tariff #2 energy reading
Tariff #3 energy reading
Tariff #4 energy reading
Tariff #5 energy reading
Tariff #6 energy reading
Tariff #7 energy reading
Tariff #8 energy reading
Description
Description
...
