Chapter 5 Configuring the EM720

Configuring DNP3

DNP Options
Number of BI to Generate
events
Binary Input Object
Binary Input Change
Event Object
Number of AI to Generate
events
116
DNP Options can be changed both via DNP3 and Modbus.
Refer to the EM720 DNP3 Reference guide for information
on the protocol implementation and a list of the available
data points.
From the Meter Setup menu select Protocol Setup and
click on the DNP Options tab.
The following table describes available DNP options. Refer
to the DNP3 Data Object Library document available from
the DNP User's Group on the DNP3 object types.
Parameter
0-64
Single-bit
With Status
Without Time
With Time
0-64
Configuring Communication Protocols
Options Default
Binary Inputs (BI)
21
3
Single-bit
With Time
Analog Inputs (AI)
43
3
EM720 Power Quality and Revenue Meter
Description
The total number of BI change
event points for monitoring
The default BI object variation for
requests with qualifier code 06
when no specific variation is
requested
The default BI change event object
variation for requests with qualifier
code 06 when no specific variation
is requested
The total number of AI change
event points for monitoring
