Satec Expertmeter EM720 Operation Manual page 182

Appendix A Parameters for Monitoring and Logging
Designation
I1 Ang
I2 Ang
I3 Ang
I4 Ang
DEMANDS
V1 DMD
V2 DMD
V3 DMD
I1 DMD
I2 DMD
I3 DMD
kW IMP BD
kvar IMP BD
kVA BD
kW IMP SD
kvar IMP SD
kVA SD
kW IMP ACD
kvar IMP ACD
kVA ACD
kW IMP PRD
kvar IMP PRD
kVA PRD
PF IMP@kVA MD
kW EXP BD
kvar EXP BD
kW EXP SD
kvar EXP SD
kW EXP ACD
kvar EXP ACD
kW EXP PRD
kvar EXP PRD
I4 DMD
HRM DMD
V1 THD DMD
V2 THD DMD
V3 THD DMD
I1 THD DMD
I2 THD DMD
I3 THD DMD
I4 THD DMD
I1 TDD DMD
I2 TDD DMD
I3 TDD DMD
I4 TDD DMD
SUMM ACC DMD
REG1 ACD
REG2 ACD
...
REG10 ACD
SUMM BLK DMD
REG1 BD
REG2 BD
...
REG10 BD
182
I1 current angle
I2 current angle
I3 current angle
I4 current angle
Present Demands
V1/V12 Volt demand
1
V2/V23 Volt demand
1
V3/V31 Volt demand
1
I1 Ampere demand
I2 Ampere demand
I3 Ampere demand
kW import block demand
kvar import block demand
kVA block demand
kW import sliding window demand
kvar import sliding window demand
kVA sliding window demand
kW import accumulated demand
kvar import accumulated demand
kVA accumulated demand
kW import predicted sliding window demand
kvar import predicted sliding window demand
kVA predicted sliding window demand
PF (import) at maximum kVA sliding window demand
kW export block demand
kvar export block demand
kW export sliding window demand
kvar export sliding window demand
kW export accumulated demand
kvar export accumulated demand
kW export predicted sliding window demand
kvar export predicted sliding window demand
I4 Ampere demand
Present Harmonic Demands
V1/V12 THD demand
1
V2/V23 THD demand
1
V3/V31 THD demand
1
I1 THD demand
I2 THD demand
I3 THD demand
I4 THD demand
I1 TDD demand
I2 TDD demand
I3 TDD demand
I4 TDD demand
Billing Summary (Total) Accumulated Demands
Register #1 accumulated demand
Register #2 accumulated demand
...
Register #10 accumulated demand
Billing Summary (Total) Block Demands
Register #1 block demand
Register #2 block demand
...
Register #10 block demand
EM720 Power Quality and Revenue Meter
Description
