Chapter 9 Viewing Log Files and Reports

Chapter 9 Viewing Log Files and
Reports

General Operations

Opening a Log File
Copying Data
Saving Data to a File
Printing Reports
EM720 Power Quality and Revenue Meter
To open a log file, click on the Open button
toolbar, or select "Open..." from the File menu. In the
"Files of type" box, select "Access Database (*.mdb)",
select a directory where your files are located, point to the
file you want to open, select a desired table on the right
pane, and then click Open.
To copy the entire data table or graph, or part of the data,
into the Clipboard or into another application such as
Microsoft Excel or Word:
1. Click on the data window with the right mouse
button and choose Select All, or, if your current
view represents a table, click on the upper-left
corner of the table (where the "No." label is
commonly displayed).
2. Click with the right mouse button on the window
again and choose Copy, or click on the Copy button
on the PAS toolbar.
3. Run the application to which you want to copy data,
position the cursor at the correct place, and then
click the Paste button
toolbar or select Paste from the Edit menu.
To save data to a file:
1. Click on the Save button
where you want your log file to be stored.
2. Select a database or type the name for a new
database.
3. Click Save.
To avoid confusion, do not store data files into the "Sites"
directory where site databases are located.
To print a data report to a printer, click on the print button
on the toolbar, select a printer and click OK. If you
General Operations
on the PAS
on the application's
, and select a directory
145
