Appendix D EN50160 Statistics Log Files
EN50160 Harmonics Survey Log (Data Log #10)
Field No.
1
2
3
4
5
...
52
1
2
3
4
5
...
52
1
2
3
4
5
...
52
EM720 Power Quality and Revenue Meter
Designation
THD MAX Maximum THD
THDO MAX Maximum odd harmonics THD
THDE MAX Maximum even harmonics THD
%HD02 MAX Maximum H02 harmonic voltage magnitude, %Un
%HD03 MAX Maximum H03 harmonic voltage magnitude, %Un
...
%HD50 MAX Maximum H50 harmonic voltage magnitude, %Un
THD MAX Maximum THD
THDO MAX Maximum odd harmonics THD
THDE MAX Maximum even harmonics THD
%HD02 MAX Maximum H02 harmonic voltage magnitude, %Un
%HD03 MAX Maximum H03 harmonic voltage magnitude, %Un
...
%HD50 MAX Maximum H50 harmonic voltage magnitude, %Un
THD MAX Maximum THD
THDO MAX Maximum odd harmonics THD
THDE MAX Maximum even harmonics THD
%HD02 MAX Maximum H02 harmonic voltage magnitude, %Un
%HD03 MAX Maximum H03 harmonic voltage magnitude, %Un
...
%HD50 MAX Maximum H50 harmonic voltage magnitude, %Un
Description
V1 Harmonic Voltage
V2 Harmonic Voltage
V3 Harmonic Voltage
