Chapter 7 Monitoring Meters
Saving Data to a File
Printing Data
Copying Data
EM720 Power Quality and Revenue Meter
mouse, or use the right and left arrow keys on your
keyboard to change the marker position. Click on the
trend pane with the mouse before using the keyboard, to
allow the keyboard to get your input.
Delta Measurements
To measure the distance between two trend points, click
on the Delta button
mouse button on the first point, and then click on the
second point. The first reference point is frozen until you
close and reopen Delta, while the second point can be
placed anywhere within the trend line. You can measure a
delta in both directions. To disable Delta, click on the
Delta button again.
Using a Zoom
You can use a horizontal and a vertical zoom to change
size of your graph. Use the buttons
toolbar representing green arrowheads to zoom in or out
of the trend graph. Every click on these buttons gives you
a 100-percent horizontal zoom. Two buttons
representing a magnifying glass give you a proportional
zoom in both directions.
To save retrieved data to a file for later analysis, click on
the Save button
your log files to be stored, select a database or type the
name for a new database, and then click Save. To avoid
confusion, do not store data files into the "Sites" directory
where site databases are located.
To print retrieved data, click the
toolbar, select a printer, and then click OK. To check the
report, as it will look when printed, select Print Preview
from the File menu.
To copy the entire data table or a part of a table into the
Clipboard or into another application such as Microsoft
Excel or Word:
Click on the Data Monitor window with the right mouse
button and choose Select All, or click on the upper-left
corner of the data table (where the "No." label is
displayed).
Click on the Data Monitor window with the right mouse
button again and choose Copy or click on the Copy button
on the PAS toolbar.
Viewing Real-time Data
on the toolbar, click with the left
, select a directory where you want
button on the PAS
on you local
137
