Chapter 9 Viewing Log Files and Reports
Viewing Waveforms
Viewing a Spectrum Table
Click on the
button on the local toolbar to display the
harmonics spectrum in a tabular view for a selected phase
or for all phases together.
The spectrum table shows voltage, current, active power
and reactive power harmonic components both in percent
of the fundamental and in natural units, and harmonic
phase angles.
EM720 Power Quality and Revenue Meter
165
