Appendix A Parameters for Monitoring and Logging

Appendix A Parameters for Monitoring
and Logging
Designation
NONE
SETPOINTS
SP1:16
SPECIAL INPUTS
PHASE ROTATION
EVENT FLAGS
EVENT FLAG 1:8
STATIC EVENTS
PHASE ORDER ERR
POS PHASE ORDER
NEG PHASE ORDER
PQ EVENT
FAULT EVENT
FAULT DETECTED
EXTERNAL TRIGGER
DEVICE FAULT
NO VOLTAGE
PULSED EVENTS
kWh IMP PULSE
kWh EXP PULSE
kvarh IMP PULSE
kvarh EXP PULSE
kvarh TOT PULSE
kVAh PULSE
START DMD INT
START TRF INT
TIMERS
TIMER 1:4
DIGITAL INPUTS
DI1:8
PULSE INPUTS
DI1:8
RELAYS
RO1:4
COUNTERS
COUNTER 1:8
TIME
DAY OF WEEK
YEAR
MONTH
DAY OF MONTH
HOURS
MINUTES
SECONDS
EM720 Power Quality and Revenue Meter
The following table
parameters available for monitoring via communication
ports, for data logging, and for triggering setpoints.
None (stub, read as zero)
Setpoint Status
Setpoints 1-16
Special Inputs (setpoint triggers only)
Phase rotation order (Error, Positive, Negative)
User Event Flags
Event Flags 1-8
Internal Static Events (setpoint triggers only)
Phase order error
Positive (ABC) phase order
Negative (ACB) phase order
PQ event. See Indication of the Power Quality
General fault event: fault recorder has been triggered. See
Indication and Cross
The embedded fault detector has detected a fault.
Fault recorder has been triggered via a digital input.
Device fault. See
No measured voltage
Internal Pulsed Events (setpoint triggers only)
kWh Import pulse
kWh Export pulse
kvarh Import pulse
kvarh Export pulse
kvarh Total pulse
kVAh pulse
Start of power demand interval pulse
Start of tariff interval pulse
Interval Timers (setpoint triggers only)
Interval timer 1-4
Digital Inputs
Digital input status DI1:DI8
Pulse Inputs (setpoint triggers only)
Transition pulse on a digital input DI1:DI8
Relays
Relay status RO1:RO4
Pulse Counters
Pulse counter 1-8
Time/Date Parameters (setpoint triggers only)
Day of week
Year
Month
Day of month
Hours
Minutes
Seconds
lists all electricity
Description
Triggering.
Device Fault Alarm.
and status
Events.
Fault
