Chapter 5 Configuring the EM720

Configuring Billing/Tariff Registers

Parameter
TOU
Use Profile
Dmd Profile
Sum Profile
Units
EM720 Power Quality and Revenue Meter
To configure the meter billing/TOU registers, select
Energy/TOU from the Meter Setup menu.
The available options are shown in the following table:
Options Default
Billing/TOU Registers
Unchecked Unchecked
Checked
Unchecked Checked
Checked
Unchecked Unchecked
Checked
Unchecked Checked
Checked
kWh None
kWh-
kvarh
kvarh-
kVAh
Configuring Billing/TOU
Description
Links multi-tariff registers to the selected
energy source
Enables recording energy registers in
monthly/daily billing profile files (both total
and tariff registers if TOU is enabled).
Always enabled for all configured billing
registers.
Enables recording maximum demand
registers in monthly/daily billing profile files
(both total and tariff registers if TOU is
enabled)
Enables recording total (summary) registers
in monthly/daily billing profile files. Always
enabled for all configured billing registers.
The register measurement unit.
Selected automatically for registers linked
to internal energy sources.
Select an appropriate measurement unit for
external pulse sources.
