Satec Expertmeter EM720 Operation Manual page 199

Appendix D EN50160 Statistics Log Files
Field No.
10
11
12
13
14
15
16
17
18
19
20
21
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
1
2
3
4
5
1
2
3
4
5
6
7
8
9
10
11
12
EM720 Power Quality and Revenue Meter
Designation
N25 200%/60s Number of polyphase incidents u>200%/t<60s
N31 110%/>60s Number of polyphase incidents u>110%/t>60s
N32 120%/>60s Number of polyphase incidents u>120%/t>60s
N33 140%/>60s Number of polyphase incidents u>140%/t>60s
N34 160%/>60s Number of polyphase incidents u>160%/t>60s
N35 200%/>60s Number of polyphase incidents u>200%/t>60s
V1 N1 Total number of incidents on phase V1
V1 Max Maximum voltage magnitude on phase V1
V2 N1 Total number of incidents on phase V2
V2 Max Maximum voltage magnitude on phase V2
V3 N1 Total number of incidents on phase V3
V3 Max Maximum voltage magnitude on phase V3
N1 110% Number of polyphase incidents u>120%
N2 150% Number of polyphase incidents u>150%
N3 200% Number of polyphase incidents u>200%
N4 250% Number of polyphase incidents u>250%
N5 300% Number of polyphase incidents u>300%
V1 N1 110% Number of incidents u>120% on phase V1
V1 N2 150% Number of incidents u>150% on phase V1
V1 N3 200% Number of incidents u>200% on phase V1
V1 N4 250% Number of incidents u>250% on phase V1
V1 N5 300% Number of incidents u>300% on phase V1
V2 N1 110% Number of incidents u>120% on phase V2
V2 N2 150% Number of incidents u>150% on phase V2
V2 N3 200% Number of incidents u>200% on phase V2
V2 N4 250% Number of incidents u>250% on phase V2
V2 N5 300% Number of incidents u>300% on phase V2
V3 N1 110% Number of incidents u>120% on phase V3
V3 N2 150% Number of incidents u>150% on phase V3
V3 N3 200% Number of incidents u>200% on phase V3
V3 N4 250% Number of incidents u>250% on phase V3
V3 N5 300% Number of incidents u>300% on phase V3
V1 Peak Max Maximum peak voltage on phase V1
V2 Peak Max Maximum peak voltage on phase V2
V3 Peak Max Maximum peak voltage on phase V3
Nnv Number of non-valid 10-min intervals
N Number of valid 10-min intervals
N1 Number of incidents V Unb > 2%, N1
N1/N, % EN50160 compliance ratio, N1/N
V Unb% Max Maximum voltage unbalance
Nnv Number of non-valid 10-min intervals
N Number of valid 10-min intervals
N1 Number of polyphase harmonic voltage incidents, N1
N2 Number of polyphase voltage THD incidents, N2
N1/N, % EN50160 harmonic voltage compliance ratio, N1/N
N2/N, % EN50160 voltage THD compliance ratio, N2/N
V1 N1 Number of harmonic voltage incidents on phase V1
V1 N2 Number of voltage THD incidents on phase V1
V1 HD% Max Worst-case harmonic magnitude on phase V1, %Un
V1 H# Worst-case harmonic component number on phase V1
V1 THD Max Worst-case voltage THD on phase V1
V2 N1 Number of harmonic voltage incidents on phase V2
Description
Transient Overvoltages (indicative statistics)
Supply Voltage Unbalance
Harmonic Voltage
