Chapter 4 Using PAS Software

Downloading Setups to the Meter

Uploading Setups from the Meter

58
You can update each setup in your meter one at a time or
download all setups together from the site database.
Individual Download
To update a particular setup in your meter:
1. Check the On-line button on the PAS toolbar
2. Select a meter site from the list box on the toolbar.
3. Select the desired setup group from the Meter
Setup menu. Click on the setup tab you want to
download to the meter. As the setup dialog box
opens, PAS retrieves and displays the present meter
setup data.
4. If you wish to download a setup saved in the site
database, click Open, and then click OK, or fill in the
boxes with the desired configuration data for your
device.
5. Click Send.
Batch Download
To download all setups to your device at once:
1. Check the On-line button on the toolbar
2. Select the device site from the list box on the
toolbar.
3. Select Download Setups from the Meter Setup
menu.
NOTE
The passwords setup is not downloaded via the Batch
Download. You can only download it individually via the
Administration Setup/Passwords dialog (see
Meter Passwords in Chapter 5).
Individual Upload
To get a particular setup from your device;
1. Check the On-line button on the PAS toolbar.
2. Select a meter site from the list box on the toolbar,
and then select the desired setup group from the
Meter Setup menu.
3. Click on the tab of the setup you want to read from
the meter. As the dialog box opens, PAS retrieves
and displays the present setup data from the meter.
Click Receive if you wish to retrieve the meter setup
once again.
4. To store the setup to the meter site database, click
Save As, and then click OK.
