Chapter 5 Configuring the EM720
100
Configuring the Fault Recorder
enable or disable RMS profiling and how to define the
maximum duration of the fault RMS profiles.
The factory pre-configured list of parameters for Data log
#13 is shown in the following table.
No.
1 1/2-cycle voltage V1/V12
2 1/2-cycle voltage V2/V23
3 1/2-cycle voltage V1/V31
4 1/2-cycle (neutral/zero-sequence) voltage V4
5 1/2-cycle current I1
6 1/2-cycle current I2
7 1/2-cycle current I3
8 1/2-cycle current I4
9 1/2-cycle zero-sequence voltage
Data Log #14
Data Log #14 is linked to the Power Quality recorder and
is configured for RMS profiling of power quality events.
You can freely manipulate this file. See
Recorder Setup in Chapter 5 on how to enable or disable
RMS profiling and how to define the maximum duration
and time envelopes for the PQ RMS profiles.
The factory pre-configured list of parameters for Data log
#14 is shown in the following table. The time integration
interval for these parameters is dynamically changed as
the event continues for more time.
No.
1 Generic voltage V1/V12
2 Generic voltage V2/V23
3 Generic voltage V1/V31
4 Generic current I1
5 Generic current I2
6 Generic current I3
7 Generic current I4
8 Generic frequency
EN50160 Statistics Data Logs
Data log #9 and Data log #10 are pre-configured for
recording EN50160 compliance statistics and harmonics
survey data. See EN50160 Statistics Log Files
D for the file layout and contents.
You cannot remove these files or change a file structure,
but you can still change the file size if you wish to collect
the EN50160 statistics data for more time.
EM720 Power Quality and Revenue Meter
Configuring Recorders
in Chapter 5 on how to
Data Log #13
Parameter
Data Log #14
Parameter
EN50160 PQ
in Appendix
