Block icons and faceplate views
3.2 Faceplates
3.2.3

Views

3.2.3.1

Batch view

The "Batch" view is available in the MMRevDhl, MMOprtn, MMStat, MMMeas and MMLog
blocks.
Batch view
This area shows a display of the batch that is currently running (
You can use the internal tag "@APLBatchEnable" to enable/disable the "Batch" button in the
toolbar.
Value of @APLBatchEnable
0
1*
*Batch ID has to be greater than 0 for Batch to be enabled.
①
②
③
④
⑤
62
Operating the "Batch" button in the
toolbar
Enabled This area shows you if the block is enabled for operation via SIMATIC BATCH
(Status1.Bit1)
(BatchEn)
Allocated This area shows if the block is currently in use by SIMATIC BATCH
(Status1.Bit0)
(Occupied)
Batch name This area shows the name of the batch that is currently running
(BatchName)
Batch ID This area shows the identification number of the batch that is currently running
(BatchID) (BatchID)
The batch view is disabled if
Batch step This area shows the step number of the batch that is currently running.
(StepNo)
Disabled
Enabled
.
BatchID
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
).
Batchview
Icon of the "Batch" button in the toolbar
= 16#00000000.
SIMOCODE pro PCS 7 Library V9.0
