4.7

MMRevDhl motor block

4.7.1

Application

4.7.1.1

Description of MMRevDhl

Purpose of the block
The MMRevDhl motor block controls the operation of a Dahlander High Feature reversing
starter.
The following commands are available in automatic mode and in manual mode:
● Forward
● Fast Forward
● Reverse
● Fast Reverse
● Stop
Use
In AUTO mode, the commands can be given based on the
mode, 1 = switch mode.
The commands for starting and stopping the motor (
FRevMan
pulse signals in manual operation.
At the
StopAut = 1
Block icons and faceplates
The MMRevDhl motor block can be indicated via 2 block icons.
The commands can be issued from the faceplate if the operator permission has been
programmed at the
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
) are reset at the end of the execution cycle of the block because the commands are
parameter, error "Invalid signal status" is indicated if
ErrorNum
, provided that
Feature.Bit4 = 0
parameter.
OS_Perm
4.7 MMRevDhl motor block
Feature.Bit4
FwdMan, FFwdMan, StopMan, RevMan,
.
Description of the blocks
: 0 = pushbutton
and
FwdAut = 1
