Example with a motor MMRevDhl: In this case, use the interconnectable input parameters.
●
FwdAut
●
RevAut
●
StopAut
●
AutModLi
●
ManModLi
Bit = 1: Switching mode: two static automatic commands are assigned to a control input.
Example with a motor MMRevDhl: In this case, use the interconnectable input parameters.
●
FwdAut
●
RevAut
●
FwdAut
●
AutModLi
●
AutModLi
The
4.1.10.6

Set switching mode

Number of the
Feature
Feature bit purpose
Specify switching mode for the motor block.
The default setting is 0.
Bit = 0: Switching mode "On over speed 1" with the SwOverTi > 0 parameter
Bit = 1: Switching mode "Off over speed 1" with the SwOverTi > 0 parameter.
4.1.10.7

Enabling direct changeover between forward and reverse

Number of the
Feature
Feature bit purpose
Enable direct reversal of the direction of motors.
The default setting is 0.
Bit = 0: Direct reversal of the direction is disabled.
You can only change the direction of the motor by first stopping and starting the motor again
in the required direction. The motor can only be started again after the time set in the
IdleTime
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
= 1 for the command "Start forward"
= 1 for the command "Start backwards"
= 1 for the stop command and
= 1 for setting "Automatic" operating mode
= 1 for setting "Manual" operating mode
= 1 for the command "Start forward"
= 1 for the command "Start backwards" and
= 0 and = 0 for the stop command
RevAut
= 1 for setting "Automatic" operating mode
= 0 for setting "Manual" operating mode
and control inputs are irrelevant in this case.
StopAut ManModLi
bit: 5
bit: 7
parameter has elapsed.
Description of the blocks
4.1 Functions for all blocks
