Description of the blocks
4.1 Functions for all blocks
4.1.10.20

Suppression of all messages

Number of the
Feature
Feature bit purpose
To determine whether all messages of the block are to be suppressed.
Bit = 0: Messages are not suppressed.
Bit = 1: Messages are suppressed.
4.1.10.21

Interlock display with LocalSetting 2 or 4

Number of the
Feature
Feature bit purpose
To specify the display of interlocks with LocalSetting 2 or 4 at the faceplate and at the
faceplate output
The default setting is 0.
Bit = 0: LocalSetting 2 and 4 crossed out locks are displayed in the standard view.
not set with interlock.
Bit = 1: LocalSetting 2 and 4 locks are displayed in the standard view according to the
interlock.
Note
A decreasing motor protection (
regardless of the
This feature bit is also applicable for the LocalSetting 5 in VlvS where LocalSetting 4 is not
available.
4.1.10.22

Define reset as a function of the mode

Number of the
Feature
Define reset as a function of the mode
Feature bit purpose
When the "Protection" interlock, feedback error ("Status error", "Control error") or "Motor
protection" signal is present again, this
88
bit: 25
bit: 27
.
LockAct
is set according to interlock. This setting is used for hardware interlock.
LockAct
bit setting.
Feature
Bit: 30
) is displayed at the output parameter
Trip.Value=0
bit is used to specify if a reset can be made
Feature
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
LockAct
LockAct
SIMOCODE pro PCS 7 Library V9.0
is
,
